Topkit Tower Crane
The Topkit Tower Cranep Manufacturer!
Mingyuandazhi Import and Export (Liaoning) Trading Co., Ltd. was established in 2009, specializing in the sales of second-hand construction machinery, tower cranes, and passenger hoists.
Why Choose Us
Experienced
After 15 years of development, we have accumulated abundant resources and industry experience, and have a professional evaluation team to ensure that every piece of equipment is professionally tested and evaluated before being sold to you.
High quality
Our brands and products all meet ISO9001 international quality standards and are at the forefront of the industry, making them trustworthy.
Our service
Qualified product quality inspection/ Prompt response to inquiries/ 24-hour after-sales guidance.
|
Standard Model |
4808 |
|
|
Max. Lift Load |
4t |
|
|
Tip Load |
0.8t |
|
|
Free Standing Height |
29m |
|
|
Max. Anchorage Height |
120m |
|
|
Jib Length |
48m |
|
|
Mast size |
1.5×1.5×2.2m |
|
|
Lift Mechanism |
Lifting Speed |
(A=2)70/35/9 m/min (A=4)35/17.5/4.5m/min |
|
Lift motor |
15/15/4kw |
|
|
Trolley Mechanism |
Trolley speed |
39/26 m/min |
|
Trolley Motor |
1.5/2.2kw |
|
|
Slewing Mechanism |
Slewing speed |
0.72r/min |
|
Slew Motor |
3.7kw |
|
|
Jacking Mechanism |
Jack climbing speed |
0.4m/min |
|
Jack climbing motor |
4kw |
|
|
Voltage |
380V/50Hz/3P |
|
Features Of Topkit Tower Crane
Stable structure
The hammer head design reduces the bending moment of the tower body, which is suitable for large-span hoisting.
Wide range of operation
The horizontal arm covers a large radius (common 40~80 meters).
Modular installation
Can be jacked as the building rises (with hydraulic jacking system).
Multi-working mode
Support leg fixing, underframe fixing, embedded bolt fixing, exterior wall attachment and other working methods to adapt to different construction needs.
High working speed and stability
Adopt frequency conversion stepless speed regulation scheme to ensure stable and reliable work.
Superior visibility and operating environment
The driver's cab is independent and external, with a wide field of vision and large internal space, providing a good working environment.
Safety & Reliability Advanced electrical control system
PLC control to improve reliability and safety.
Durable electrical components
The introduction of foreign advanced technology to produce electrical components, the service life is 3~4 times longer than that of domestic components, less failures, simple maintenance.
Applicability of a wide range of application scenarios
Suitable for a variety of construction objects, including high-rise buildings, bridges, ports and other large-scale projects.
International popular design
The appearance of the whole machine is beautiful, in line with the international fashion trend.
If you interested in our products, please provide the following parameters:
1) Jib span/jib length (m)
2) Max load capacity (ton)
3) Tip load capacity (ton)
4) Liffing height (m)
5) Local power supply (KV, Hz)
6) Other special requirement
We will provide best price once confirmed the above.
Safety Features
|
1 |
Torque limiter |
Control torque, it will warns when lifting weights reach to 90% of rated lifting torque. When reach to 110% of the rated lifting torque, it will limit rising upwards and trolley. |
|
2 |
Weight limiter |
Control the maximum lifting capacity, lifting weight reach to 40% of the rated capacity, limit high-speed lifting; lifting weight reach to 110% of the rated capacity, limit the lifting up |
|
3 |
Height limiter |
Control the lowest and highest extreme position of lifting hook |
|
4 |
Slewing limiter |
Control the extreme turns number of turn left and right |
|
5 |
Amplitude limiter |
Control trolley limit position of inward and outward |
|
6 |
Overload protection |
If the material is over the capacity, the crane will give a sharp warning for protection itself |
|
7 |
Emergency brake |
If the operation staff encounter some emergency situation, we could start the emergency brake system to protection the related treasure |
|
8 |
Control Method |
Room control or remote control to avoid any injury to the operation staff |
|
9 |
Main lifting motor |
With thermal protection and currency protection |
Packing Details
We will packing by professional export packing,safety against breakage, finally into the wooden cases/ carton/pallet or customized package.
Delivery Details
We can deliver by SEA,air,rail transportation,the China-Europe Railway Express etc. TNT, DHL,UPS, FEDEX, EMS，S.F EXPRESS etc.
