Building Material Hoist

Building Material HoistIt is an efficient vertical transportation equipment designed for high-rise buildings, bridge construction and large-scale industrial projects, and undertakes the task of fast and safe transportation of building materials, personnel and equipment. Through the combination of high-strength structural design, intelligent safety control and energy-saving drive technology, our products ensure transportation efficiency and operation safety under harsh working conditions such as extreme loads, high altitudes and dust, and meet the triple strict requirements of modern construction for transportation efficiency, economy and reliability.

1. Superior lifting speed

Lifting speed: 0-63m/min stepless speed regulation (speed fluctuation <5%)

2. Multiple safety protection system, the accident rate tends to be close to zero

Integrated six-fold active safety mechanism, covering mechanical, electrical and intelligent protection:

Overload protection: real-time monitoring of load capacity

Fall arrester: two-way progressive braking, braking torque ≥ 120kN·m (in accordance with EN 12159 standard).

Door interlock device: It is forbidden to start when the door on all floors is not closed to avoid the risk of falling from height.

Wind speed monitoring: When the wind speed > 20m/s (level 8 wind), the speed will be automatically reduced to safe mode.

Emergency descent system: When the power is off, the hydraulic brake can be manually released to descend smoothly to the nearest floor.

AI visual monitoring: real-time identification of violations of personnel in the cage (such as overcrowding, not wearing safety helmets), and voice warning.

3. Modular quick-assembly design, construction efficiency increased by 70%

With pre-assembled standard section + bolt connection, the on-site installation time is reduced by 70% compared with the traditional bolt type.

Innovative Design:

Laser calibration interface: standard section docking accuracy ±0.5mm, verticality error < 1/1000.

Hydraulic synchronous jacking system: the installation time of a single section is ≤ 3 minutes, and there is no need for high-altitude welding in the whole process.

Key Benefits:

The erection time at a height of 100 meters has been reduced from 72 hours to 22 hours, and labor costs have been reduced by 60%.

It supports rapid disassembly and off-site reorganization, and adapts to the needs of multi-site circulation.

4. Energy-saving drive technology, reducing operating costs by 40%

Using permanent magnet synchronous motor + frequency conversion control, the power conversion efficiency reaches 95%, and with the potential energy feedback system, the descending kinetic energy is converted into electric energy and returned to the power grid.

Key figures:

Energy consumption comparison: Compared with traditional asynchronous motors, a single unit saves about 28,000kW·h of electricity per year (based on an average of 10 hours of daily operation).

Feedback efficiency: the potential energy recovery rate is ≥35%, and the annual electricity cost is saved by more than 35,000 yuan (electricity price is 0.8 yuan/kWh).

Key Benefits:

Reduce carbon emissions by about 22 tons/year (equivalent to planting 1,200 trees) and contribute to green construction certification.

The temperature rise of the motor is reduced by 30°C, which prolongs the service life of the equipment.

5. Adaptability to harsh environments, global scene coverage

Tested in extreme environments to ensure reliable operation:

Dustproof and waterproof: IP65 protection level (can resist high-pressure water gun flushing and dust ingress).

Corrosion-resistant design: The surface of key components is hot-dip galvanized + epoxy coating, and it has passed the 5,000-hour salt spray test (ASTM B117).

6. Intelligent management platform (standard)

Integrate Internet of Things (IoT) modules to monitor equipment status in real time and generate multi-dimensional data analysis reports:

Core Functions:

Running trajectory tracking: record the position, speed and load data of the cage with an accuracy of ±0.1 meters.

Preventive maintenance reminder: Based on the vibration spectrum analysis of bearings, the failure is warned 2 months in advance.

Electronic fence: set the safe working area, automatically stop and alarm when crossing the boundary.

Key Benefits:

25% increase in equipment utilization, reducing unplanned downtime losses.

Data reporting complies with ISO 55000 asset management standards and supports engineering audits and insurance assessments.

24-hour online service

Remote diagnostic services

In case of emergency, spare parts are delivered at regular intervals

Industry accumulation: With 20 years of industry experience, professional team, many brands of second-hand construction lifts to choose from.

Cost advantage: large-scale supply, the price is 35% lower than that of European and American brands, and the delivery cycle is ≤ 30 days.

Zero accident record: more than 6000+ devices have been delivered worldwide, with a failure rate of <0.1%.

Act now to get your exclusive plan and quote!
